| SPECIFICATION |
LA4MH |
LA4MHA |
| Type |
4”, 2-way Mid-High, Linearray Module |
4”, 2-way Mid-High, Linearray Module |
| Frequency Range (-10dB) |
95Hz~18kHz |
95Hz~18kHz |
| Frequency Response (±3dB) |
105Hz~17kHz |
105Hz~17kHz |
| Coverage Pattern |
100°V x 20°H nominal |
100°V x 20°H nominal |
| Sensitivity (1w/1m) (SPL) |
90 dB |
90 dB |
| Sensitivity Max. (SPL) |
112 dB |
112 dB |
| Power Rating (Continuous/Program) |
80/160 watts |
80/160 watts |
| Nominal Impedance |
16 Ohms |
16 Ohms |
| Crossover Frequency |
3.5 kHz |
3.5 kHz |
| Drivers |
LF: 2×4″/HF: 1X1″ |
LF: 2×4″/HF: 1X1″ |
| Appearance Finish |
Water-borne (Green Eco), Sand texture painting (4 times) |
| Dimensions (WxHxD) |
394x165x360mm |
394x165x360mm |
| Package (WxHxD) |
450x405x400mm |
450x405x400mm |
| Q’ty for package |
2 PCS / 1CTN |
2 PCS / 1CTN |
| Weight (Kg) |
6 |
7.5 |
