| Output Power (1kHZ, 0.01% THD+N) |
P-302 |
P-502 |
P-702 |
P-902 |
| RMS into 8 Ohm(stereo mode) |
350W |
500W |
700W |
900W |
| RMS into 4 Ohm(stereo mode) |
520W |
750W |
1050W |
1350W |
| RMS into 2 Ohm(stereo mode) |
/ |
/ |
/ |
/ |
| RMS into 8 Ohm(bridge mode) |
1040W |
1500W |
2100W |
2700W |
| RMS into 4 Ohm(bridge mode) |
/ |
/ |
/ |
/ |
| Frequency Response(0/-1dB, 1W/8Ω) |
20-20KHz |
20-20KHz |
20-20KHz |
20-20KHz |
| THD+N (at 8Ω/1kHz and -dB under clip) |
<0.09% |
<0.09% |
<0.09% |
<0.09% |
| Damping Factor (10-400Hz/8Ω) |
300:1 |
400:1 |
500:1 |
500:1 |
| Input Sensitivity (8 ohm stereo) |
1V |
1V |
1V |
1V |
| Input Impedance (bal/unbal) |
>20k/>10k |
>20k/>10k |
>20k/>10k |
>20k/>10k |
| S/N(dB) |
-100dB |
-100dB |
-100dB |
-100dB |
| Connector Input |
XLR |
XLR |
XLR |
XLR |
| Connector Output |
2xSpeakon |
2xSpeakon |
2xSpeakon |
2xSpeakon |
| Operating Voltage |
~220V, 50Hz |
~220V, 50Hz |
~220V, 50Hz |
~220V, 50Hz |
| Dimension (WxHxD) mm |
483x89x451mm |
483x89x451mm |
483x89x451mm |
483x89x451mm |
| Net Weight (kg) |
15 |
16.5 |
20.5 |
24 |
