| Specification |
RQM10/10A |
RQM12/12A |
RQM15/15A |
| Type |
10″ , 2-Way Fullrange, Multi-function type. |
12″ , 2-Way Fullrange, Multi-function type. |
15″ , 2-Way Fullrange, Multi-function type. |
| Frequency Range(-10dB) |
60Hz~18kHz |
60Hz~18kHz |
50Hz~18kHz |
| Frequency Response(+3dB) |
70Hz~17kHz |
70Hz~17kHz |
60Hz~17kHz |
| Coverage pattern |
90°H X 60°V nominal |
60°H X 40°V nominal |
60°H X 40°V nominal |
| Sensitivity(1W/1m) (SPL) |
96 dB |
98 dB |
101 dB |
| Sensitivity Max.(SPL) |
121 dB |
124 dB |
129 dB |
| Power Rating (Continous/Program/Peak) |
150 / 300 / 600 watts |
200 / 400 / 800 watts |
300 / 600 / 900 watts |
| Nominal Impedance |
8 Ohms |
8 Ohms |
8 Ohms |
| Input Connectors |
2XSpeakon, NL4, 1+ / 1- (Linked from input to output) |
2XSpeakon, NL4, 1+ / 1- (Linked from input to output) |
2XSpeakon, NL4, 1+ / 1- (Linked from input to output) |
| Crossover Mode |
Passive |
Passive |
Passive |
| Crossover Frequency |
3 kHz |
3.5 kHz |
3 kHz |
| Drivers |
HF: 1X1″ / LF: 10″x1 |
HF: 1X1″ / LF: 12″x1 |
HF: 1X1″ / LF: 15″x1 |
| Enclosure |
15mm Plywood |
15mm Plywood |
18mm Plywood |
| Appearance Finish |
Water-borne (Green Eco), Sand texture painting (4 times) |
Water-borne (Green Eco), Sand texture painting (4 times) |
Water-borne (Green Eco), Sand texture painting (4 times) |
| Dimensions (W×H×D) |
335X500X305 |
385X565X345 |
432X690X375 |
| Package(W×H×D): |
385X545X350 |
425X615X385 |
485X735X415 |
| Q’ty for package |
1 PCS / 1 CTN, Inner and outer carton, double package. |
1 PCS / 1 CTN, Inner and outer carton, double package. |
1 PCS / 1 CTN, Inner and outer carton, double package. |
| Weight (Kg) |
14/15 |
18/19 |
25.5/27 |
| Suspensive/Mounting |
35mm tube socket, M8 X 3 Screw nuts for U-Bracket or wire flying. |
35mm tube socket, M8 X 3 Screw nuts for U-Bracket or wire flying. |
35mm tube socket, M8 X 3 Screw nuts for U-Bracket or wire flying. |
| Technical Data for Amp. Module |
RQM10A |
RQM12A |
RQM15A |
| Output Power |
250W RMS |
350W RMS |
500W RMS |
| Input Type |
Balanced differential |
Balanced differential |
Balanced differential |
| Input Impedance |
20K Ohms |
20K Ohms |
20K Ohms |
| Rated THD |
<0.03% |
<0.03% |
<0.03% |
| Line Connectors |
Line: XLR |
Line: XLR |
Line: XLR |
| Output Connectors |
Line Loop Thru: XLR / Male; Mic. Input: Combo Jack |
Line Loop Thru: XLR / Male; Mic. Input: Combo Jack |
Line Loop Thru: XLR / Male; Mic. Input: Combo Jack |
| Operation Voltage |
~100-240V |
~100-240V |
~100-120V or ~220-240v |
