| Features & Application |
| 1. Stand installation with monitor type (two-way type) |
| 2. HF driver with 1″ Voice Coil. |
| 3. LF driver with 8″ (100 watt/RMS). |
| 4. 8″ 2-way passive fullrange system. |
| 5. Rotatable logo Badge. |
| 6. Water-borne sand texture painting appearance (4 times) |
| 7. Compact design. |
| 8. Double carton package. |
| Specification |
| Type |
8″ , 2-Way Fullrange System, monitor type |
| Frequency Range(-10dB) |
80Hz~20kHz |
| Frequency Response( +3dB) |
70Hz~18kHz |
| Coverage pattern |
90°H X 90°V nominal |
| Sensitivity(1W/1m) (SPL) |
96 dB |
| Sensitivity Max.(SPL) |
118 dB |
| Power Rating (Continous/Program/Peak) |
100 / 200 / 400 watts |
| Nominal Impedance |
8 Ohms |
| Crossover Frequency |
5 kHz |
| Drivers |
HF: SM8/SUIM X 1, LF: TC-8/100SM / SUIM X 1 |
| Enclosure |
12mm Plywood |
| Appearance Finish |
Water-borne (Green Eco), Sand texture painting (4 times) |
| Dimensions (W×H×D) |
250X325X250mm |
| Package(W×H×D): |
300X370X290mm |
| Q’ty for package |
1 PCS / 1 CTN |
| Weight (Kg) |
6kg |
